WiFi on Onion Omega Series

The Onion Omega series comes with built-in WiFi, enabling seamless wireless communication for IoT projects. With its WiFi capabilities, the Omega can easily connect to networks, communicate with remote servers, and interact with other devices in your system.

WiFi Features

• Built-in 802.11b/g/n WiFi for fast, reliable wireless communication.
• Supports WPA/WPA2 encryption for secure wireless connections.
• Easy setup via the web interface or terminal commands.
• Ability to create a WiFi hotspot, allowing the Omega to function as an access point.

Connecting to a WiFi Network

To connect the Omega to a WiFi network, follow these steps:

1. Access the Omega's web interface or SSH into the device.
2. Use the following command to scan available networks:

   iw dev wlan0 scan

3. Connect to your network using the following command:

   wifi config wlan0 -i  -p

Ethernet on Onion Omega Series

The Onion Omega series is designed primarily for WiFi connectivity, but it also supports Ethernet connections via a USB-to-Ethernet adapter. This feature allows the Omega to connect to wired networks, making it an excellent choice for applications requiring a stable, high-speed connection.

Using Ethernet with Onion Omega

To use Ethernet with the Onion Omega, you need to connect a compatible USB-to-Ethernet adapter to the USB port of the Omega device. The Omega will automatically recognize the adapter, and you can configure the network settings through the web interface or using the terminal.

Enabling Ethernet Connection

Once the Ethernet adapter is connected, the following steps can be followed to configure the connection:

1. Connect the USB-to-Ethernet adapter to the Omega's USB port.
2. Access the Omega's web interface or SSH into the device.
3. Run the following command to configure the network interface:

   ifconfig eth0 up

4. Use the following command to get the IP address assigned to the Ethernet interface:

   ifconfig eth0

I2C on Onion Omega Series

The Onion Omega series supports the I2C (Inter-Integrated Circuit) communication protocol, which is commonly used for connecting microcontrollers and peripherals such as sensors, displays, and EEPROMs. I2C allows multiple devices to communicate over a two-wire bus: one for data (SDA) and one for clock (SCL).

I2C Features on Onion Omega

• Supports multiple I2C devices on the same bus.
• Uses standard 3.3V logic, ensuring compatibility with many devices.
• Easy configuration via the command line or programming interfaces.
• Compatible with a variety of I2C sensors and devices like temperature sensors, displays, and ADCs.

Enabling I2C on Onion Omega

By default, the I2C interface is not enabled on the Omega. To enable I2C, follow these steps:

1. SSH into your Onion Omega device.
2. Run the following command to enable I2C:

   echo "i2c-gpio" > /sys/module/i2c_bcm2708/parameters/i2c0

3. Confirm that the I2C bus is available by checking the device tree:

   ls /dev/i2c-0

Using I2C with Devices

Once I2C is enabled, you can start communicating with I2C devices. You can use a tool like i2c-toolsor a programming language like Python to interact with I2C peripherals. The common I2C tools are i2cdetect, i2cget, and i2cset, which allow you to detect devices, read, and write data to I2C addresses.

Example: Detecting I2C Devices

Use the i2cdetectcommand to scan for connected I2C devices:

i2cdetect -y 0

This will display a matrix showing the I2C addresses of all devices connected to the bus.

Example: Reading Data from an I2C Device

Once you have detected your I2C device, you can read data from it using the i2cgetcommand:

i2cget -y 0 0x48 0x01

This example reads data from address 0x48 (a common I2C address for a temperature sensor) at register 0x01.

Using Python for I2C

Python is a popular choice for communicating with I2C devices on the Omega. The SMBuslibrary makes it easy to communicate with I2C devices using Python.

Example: Python Code to Read from an I2C Device

import smbus

# Initialize the SMBus
bus = smbus.SMBus(0)

# Define the I2C address of the device
device_address = 0x48

# Read a byte of data from register 0x01
data = bus.read_byte_data(device_address, 0x01)

print(f"Data: {data}")


This example demonstrates how to initialize the I2C bus and read a byte of data from a device with address 0x48, which could be a temperature sensor or similar device.

Audio on Onion Omega Series

The Onion Omega series offers basic support for audio playback and input through various methods, including digital audio output, analog audio output, and software libraries. While the Omega does not have a dedicated audio chip like some other boards, it is flexible enough to interface with external audio hardware such as USB sound cards, audio shields, and I2S devices. Additionally, it can generate and process audio using its software capabilities.

Audio Output Options

The Omega offers multiple ways to output audio:

• USB Audio: You can use a USB audio adapter to provide high-quality audio output through the USB port. This method requires a compatible USB sound card or audio interface.
• I2S Audio: The Omega supports I2S (Inter-IC Sound) for connecting external audio chips, such as DACs (digital-to-analog converters) and audio amplifiers. I2S allows for high-quality, low-latency audio output.
• Analog Audio (PWM): Audio output can also be achieved using Pulse Width Modulation (PWM). While this is not ideal for high-fidelity audio, it can be used for simple audio signals.

Audio Input Options

For audio input, the Omega can interface with USB audio devices or use GPIO pins in combination with external components. Some options include:

• USB Audio: Like audio output, USB audio input is supported with compatible USB audio interfaces or microphones.
• Analog Audio: Audio input via the GPIO pins is possible, though additional circuitry like amplifiers or ADCs may be required for high-quality audio input.

Configuring USB Audio Devices

To use a USB audio device, simply plug the USB audio adapter into one of the USB ports on the Onion Omega. The device should be automatically detected by the Omega. You can configure and control it using the following steps:

1. SSH into your Onion Omega device.
2. Run the following command to check if the device is recognized:

   lsusb

3. If the device is detected, use the aplaycommand to output audio:

   aplay /path/to/audiofile.wav

4. You can also control volume and playback settings using alsamixerand other ALSA tools.

Using I2S for Audio

The Omega can interface with I2S audio peripherals like DACs or audio codecs. The I2S interface allows for high-quality audio output at a lower latency than PWM. Here’s how you can enable and use I2S on the Onion Omega:

1. Ensure that I2S peripherals (such as a DAC or audio codec) are connected to the correct GPIO pins.
2. Use a library like onion-i2s to configure I2S and send audio data.
3. Example Python code for sending audio data over I2S:


   import I2S

   # Initialize I2S interface
   i2s = I2S.I2S()

   # Send audio data to I2S DAC
   i2s.write(data)


Audio Software Support

On the Onion Omega, you can use a variety of software tools to work with audio. The Omega is compatible with standard Linux audio software packages such as ALSA (Advanced Linux Sound Architecture) and PulseAudio. These tools allow you to control audio settings, record audio, and play audio files directly from the command line or through scripts.

Installing ALSA for Audio Control

To install ALSA and related tools on the Onion Omega, use the following command:

opkg update
opkg install alsa-utils

Playing Audio Files

Once ALSA is installed, you can play audio files directly from the command line. For example:

aplay /path/to/audiofile.wav

This will send the audio to the default sound device on the Omega.

Limitations

While the Onion Omega provides several options for handling audio, it is important to note that it is not primarily designed as an audio-focused device. As such, high-quality, low-latency audio applications may require additional hardware or configuration. For critical applications, it is recommended to use dedicated audio interfaces such as USB sound cards or I2S DACs.

Supported Models

The audio features described here are available on all Onion Omega models. However, external peripherals such as USB audio devices and I2S DACs will determine the audio quality and functionality available on your device. Here’s a summary of the Omega models:

• Onion Omega 2
• Onion Omega 2+
• Onion Omega 2S

SPI on Onion Omega Series

The Onion Omega series supports the SPI (Serial Peripheral Interface) communication protocol, which is widely used for connecting high-speed peripherals like sensors, displays, SD cards, and EEPROMs. SPI is a full-duplex communication protocol that uses separate lines for data input, data output, clock, and chip select, making it ideal for high-speed data transfer.

SPI Features on Onion Omega

• High-speed communication with devices like displays, SD cards, and sensors.
• Multiple SPI devices can be connected using different chip select (CS) lines.
• 3.3V logic, compatible with most modern peripherals.
• SPI hardware support for fast data transfer rates.
• Easy configuration via the command line or programming interfaces.

Enabling SPI on Onion Omega

By default, SPI is not enabled on the Omega. To enable SPI, follow these steps:

1. SSH into your Onion Omega device.
2. Run the following command to enable the SPI bus:

   echo "spi-bcm2708" > /sys/module/spi_bcm2708/parameters/spi0

3. Verify the SPI bus is available:

   ls /dev/spidev0.0

Using SPI with Devices

Once SPI is enabled, you can start communicating with SPI devices. You can use tools like spidevor programming languages like Python to interact with SPI peripherals. Common tools for SPI communication include <code>spi-config, spidev-test, and Python libraries like spidev.

Example: Communicating with an SPI Device

Below is an example of how to use the spidevcommand to communicate with an SPI device.

# Send a command to an SPI device at SPI bus 0, chip select 0
spidev -d /dev/spidev0.0 -b 50000 -s 0x01


This example communicates with an SPI device using SPI bus 0, chip select 0, and sends the command 0x01at a clock speed of 50,000 Hz.

Using Python for SPI

Python is an excellent language for interacting with SPI devices, and the spidevlibrary is commonly used on the Omega. This library provides a simple interface for setting up the SPI bus and communicating with devices.

Example: Python Code to Communicate with an SPI Device

import spidev

# Initialize the SPI bus
spi = spidev.SpiDev()

# Open SPI bus 0, device 0
spi.open(0, 0)

# Set SPI speed and mode
spi.max_speed_hz = 50000
spi.mode = 0

# Send data to the device
response = spi.xfer2([0x01])

print(f"Response from SPI device: {response}")

# Close SPI bus
spi.close()


This Python example demonstrates how to open the SPI bus, set parameters like speed and mode, communicate with an SPI device by sending data, and then close the SPI bus.

Timer and PWM on Onion Omega Series

The Onion Omega series supports timers and pulse-width modulation (PWM), which are essential for time-based tasks and controlling actuators like motors and LEDs. PWM allows for efficient control of the duty cycle of digital outputs, making it ideal for applications like motor control or dimming LEDs.

Using Timers on Omega

Onion Omega provides a set of timers that can be used for generating time delays, scheduling tasks, or creating periodic events. These timers can be configured to trigger interrupts or execute tasks at specified intervals.

Using PWM on Omega

PWM can be used to control the brightness of LEDs, motor speeds, and other devices that require variable voltage control. The Omega series supports PWM on several GPIO pins, and you can control the frequency and duty cycle through software.

Configuring PWM

Use the following commands to set up PWM on a GPIO pin:

echo "pwm" > /sys/class/gpio/export
echo "50" > /sys/class/gpio/pwm0/duty_cycle
echo "1000" > /sys/class/gpio/pwm0/frequency


Serial Communication on Onion Omega Series

The Onion Omega series provides serial communication capabilities, allowing it to interface with a variety of serial devices like sensors, controllers, or other microcontrollers. The Omega supports both UART and USB-based serial communication.

Using UART Serial on Omega

To use UART on the Omega, you need to connect the appropriate UART pins (TX/RX) to the serial device. The Omega supports standard 3.3V logic levels for serial communication.

Setting Up Serial Communication

To communicate over serial, follow these steps:

1. Access the Omega via SSH.
2. Enable the UART serial port by running:

   stty -F /dev/ttyS0 115200

3. Use a program like Minicom or screen to communicate over the serial interface.

GPIO on Onion Omega Series

The Onion Omega series offers GPIO pins that allow you to interface with a wide range of devices such as LEDs, buttons, sensors, and relays. These pins are capable of digital input and output and can be configured for various applications.

Using GPIO on Omega

The Omega uses a simple file-based interface to control GPIO pins. You can easily export GPIO pins, configure them as input or output, and read or write their states through the command line or scripts.

Basic GPIO Commands

To control GPIO pins, use the following commands:

1. Export the GPIO pin:

   echo "X" > /sys/class/gpio/export

2. Set the pin direction (input or output):

   echo "in" > /sys/class/gpio/gpioX/direction

3. Write to the pin:

   echo "1" > /sys/class/gpio/gpioX/value

Onion Omega Web Interface

The Onion Omega series features a web-based configuration interface called the Console. This web interface provides an easy-to-use GUI for managing system settings, network configurations, and installing software packages.

Accessing the Web Interface

By default, the Omega runs a lightweight web server that hosts the Console. You can access it using any modern web browser.

1. Connect your computer to the Omega’s WiFi (default SSID: Omega-XXXX).
2. Open a web browser and go to http://omega-XXXX.local or http://192.168.3.1.
3. Log in using the default credentials:
   • Username: root
   • Password: (Set during first setup)

Features of the Web Console

The web interface allows users to perform various system management tasks:

• Dashboard – View system status including CPU usage, memory, and storage.
• WiFi Setup – Configure WiFi settings to connect the Omega to an existing network.
• File Manager – Browse and manage files stored on the device.
• Terminal – Access a built-in web-based command line interface.
• Package Manager – Install and update software packages.
• App Store – Install additional Onion Omega apps.
• System Settings – Manage hostname, password, and network settings.

Installing Additional Web Applications

The Omega supports adding custom web applications via the web server. You can install additional packages to expand the functionality:

# Update package list
opkg update

# Install a lightweight web server
opkg install lighttpd

# Start the web server
/etc/init.d/lighttpd start


Developing Custom Web Pages

You can host your own web applications on the Omega by placing HTML, JavaScript, and PHP files in the web server directory:

# Default web server directory
cd /www

# Create an index.html file
echo "<h1>Welcome to my Omega Web Interface</h1>" > /www/index.html


Enabling Remote Access

To access the web interface from a remote network, configure port forwarding on your router or use Onion Cloud services for secure remote management.

Conclusion

The web-based interface on Onion Omega provides a convenient way to manage the device, configure settings, and even develop custom web applications. With its built-in Console and the ability to host additional web pages, it is a flexible tool for IoT and embedded applications.

Handling Interrupts on Onion Omega

Interrupts allow the Onion Omega to respond to external events asynchronously, making it ideal for handling real-time inputs such as button presses, sensor triggers, and other hardware signals.

Supported Interrupt Sources

• GPIO Interrupts – Detects changes in input state.
• Timer Interrupts – Allows precise timing operations.
• Peripheral Interrupts – Generated by I2C, SPI, UART, and other hardware modules.

Configuring GPIO Interrupts

Onion Omega GPIO pins can be configured to trigger an interrupt when their state changes. The typical edge detection modes include:

• Rising Edge – Triggered when a pin changes from LOW to HIGH.
• Falling Edge – Triggered when a pin changes from HIGH to LOW.
• Both Edges – Triggered on any state change.

Example: Setting Up a GPIO Interrupt

The following example demonstrates how to configure an interrupt on GPIO 0 using the Omega's fast-gpioutility.

# Install fast-gpio utility if not already installed
opkg update
opkg install fast-gpio

# Configure GPIO 0 as an input
fast-gpio set-input 0

# Attach an interrupt to GPIO 0, triggering on falling edge (button press)
fast-gpio set-interrupt 0 falling


Handling Interrupts in Python

For more advanced applications, you can use Python to handle GPIO interrupts using the OPi.GPIOlibrary.

import OPi.GPIO as GPIO
import time

# Use GPIO 0 for the interrupt
interrupt_pin = 0

# Callback function to handle the interrupt
def button_pressed(channel):
    print("Interrupt detected on GPIO", channel)

# Set up GPIO
GPIO.setmode(GPIO.BOARD)
GPIO.setup(interrupt_pin, GPIO.IN, pull_up_down=GPIO.PUD_UP)

# Add event detection
GPIO.add_event_detect(interrupt_pin, GPIO.FALLING, callback=button_pressed, bouncetime=300)

# Keep the script running
try:
    while True:
        time.sleep(1)
except KeyboardInterrupt:
    GPIO.cleanup()


Using Interrupts in C

For high-performance applications, interrupts can be handled in C using the Omega SDK.

#include <stdio.h>
#include <stdlib.h>
#include <fcntl.h>
#include <unistd.h>
#include <poll.h>

#define GPIO_PIN "0"

int main() {
    char path[40];
    snprintf(path, sizeof(path), "/sys/class/gpio/gpio%s/value", GPIO_PIN);

    int fd = open(path, O_RDONLY);
    if (fd < 0) {
        perror("Failed to open GPIO");
        return 1;
    }

    struct pollfd pfd;
    pfd.fd = fd;
    pfd.events = POLLPRI;

    while (1) {
        lseek(fd, 0, SEEK_SET);
        char buffer[10];
        read(fd, buffer, sizeof(buffer));

        printf("Waiting for interrupt...\n");
        poll(&pfd, 1, -1);
        printf("Interrupt detected on GPIO %s\n", GPIO_PIN);
    }

    close(fd);
    return 0;
}


Interrupt Priority and Performance

For real-time applications, interrupt priority can be managed using kernel configurations or by handling events in low-level C instead of user-space scripts.

Conclusion

GPIO interrupts on Onion Omega provide an efficient way to handle external signals without constantly polling for changes. Using Python, Bash, or C, developers can build responsive and efficient embedded applications.

Operating Systems on Onion Omega Series

The Onion Omega series is primarily designed to run a Linux-based operating system, but it also supports alternative operating systems such as RTOS (Real-Time Operating Systems) and bare-metal programming for specialized applications. Below is a detailed guide on the default OS, how to reinstall it, and other operating system alternatives available for the Onion Omega series.

Default Operating System: Omega OS

The default operating system for the Onion Omega series is Omega OS, which is a custom Linux distribution based on OpenWRT. It is designed specifically for embedded development and IoT applications, providing a lightweight and flexible environment for running a variety of applications.

Omega OS is optimized for the Onion Omega's hardware and includes various tools and packages needed for embedded development. It comes with a minimal web interface for configuration and software management, making it simple to get started with your projects.

Key Features of Omega OS:

• Based on OpenWRT Linux distribution.
• Supports popular programming languages like Python, Node.js, and more.
• Access to a wide range of software packages via the opkgpackage manager.
• Web-based interface for easy configuration and monitoring.
• Lightweight, fast booting, and optimized for IoT applications.

Reinstalling Omega OS

If you need to reinstall Omega OS on your Onion Omega device, follow these steps:

1. Download Omega OS Image

First, download the latest version of Omega OS from the Onion IoT website:

• Download Omega OS

2. Prepare the SD Card

To reinstall the OS, you will need a microSD card with at least 4 GB of storage. Use an SD card reader to connect the card to your computer.

Format the SD card using a tool like SD Formatteror the built-in disk utility of your operating system to ensure the card is clean and ready for installation.

3. Flash the Image

Use an image flashing tool to write the Omega OS image to the SD card:

• On Windows, use Balena Etcher to flash the image.
• On Linux, use the ddcommand to write the image:

sudo dd if=omega_os_image.img of=/dev/sdX bs=4M status=progress && sync

4. Boot the Onion Omega

Insert the SD card into the Onion Omega and power it on. The device will boot into Omega OS automatically. You can now proceed with the initial setup, which includes connecting to a Wi-Fi network, setting up SSH access, and configuring the system.

Alternative Operating Systems

While Omega OS is the default and recommended operating system, you can also run alternative operating systems on the Onion Omega series, including RTOS or bare-metal programming for more specialized use cases.

1. Real-Time Operating Systems (RTOS)

Real-Time Operating Systems are used in applications where precise timing and quick response times are critical, such as robotics or automation systems. Some RTOS options you can consider for the Onion Omega include:

• FreeRTOS: A lightweight and widely-used RTOS for embedded systems. It supports multi-threading, task scheduling, and real-time clock management.
• ChibiOS: A compact and fast RTOS designed for real-time applications, with low memory usage and a focus on performance.
• RIOT OS: An open-source RTOS designed for IoT devices, with a focus on low-power operation and scalability.

To use an RTOS, you will need to build it from source and load it onto the Omega. For most RTOSes, this involves setting up a cross-compilation environment and flashing the firmware to the device.

2. Bare-Metal Programming

Bare-metal programming involves writing programs directly to the hardware without using an operating system. This is useful for applications that require maximum control over the hardware and minimal overhead.

To get started with bare-metal programming on the Onion Omega, you will need a toolchain that supports the MIPS architecture and tools for flashing the firmware onto the Omega. You can write code in C or assembly, compile it using a cross-compiler, and then load the program onto the device. Some key resources to help you get started include:

• Onion Developer Resources
• Onion GitHub Repositories

Conclusion

The Onion Omega series provides a versatile platform that supports the default Omega OS based on OpenWRT, as well as alternative operating systems like FreeRTOS, ChibiOS, and bare-metal programming. Whether you're working on an IoT project, real-time application, or need to run custom firmware, the Omega can accommodate a variety of use cases. By following the steps outlined above, you can easily install and configure the OS of your choice for your project needs.

sudo mkfs.ext4 /dev/sdX

sudo mount /dev/sdX1 /mnt
sudo mkdir /mnt/storage

mount -o rw /dev/mtdblock0 /mnt/omega

cp -a /mnt/omega/home /mnt/storage/
cp -a /mnt/omega/usr /mnt/storage/

/etc/fstab

vi /etc/fstab

/dev/mmcblk0p1 /home ext4 defaults 0 0
/dev/mmcblk0p1 /usr ext4 defaults 0 0

printenv

setenv bootcmd 'bootm 0x9f000000'
saveenv

reboot

df -h
